Dometic S4

Spezifikationen

Allgemein

Scope of delivery

S4S Top hung window with manual in box

SKUCertificates

ECE R43

Product Description

Ausstellfenster, 550 x 600

Abmessungen

Dimensions product height, [mm]

631

Dimensions product width, [mm]

594

Dimensions product width, ["] - Display

23 6/16

Dimensions ordered height, [mm]

600

Dimensions ordered width, [mm]

550

Net weight, [kg]

6.40

Net weight, [lbs]

14.11

Standard mount. material thickness 1 min, [mm]

26

Standard mount. material thickness 1 max, [mm]

26

Possible material thickness 1 min, [mm]

27

Possible material thickness 1 max, [mm]

41

Cut out height, [mm]

599.000000

Cut out width, [mm]

548.000000

Eigenschaften

Hinge type

Aufklappscharnier

Positions variable

Variable

Logistik

Dimensions parcel depth, [mm]

650

Dimensions parcel height, [mm]

185

Dimensions parcel width, [mm]

700

Parcel weight, [kg]

7.60

Parcel weight, [lbs]

16.76
