SKU: 9104115552
Looking for a top-quality, attractive window to enhance the side of your motorhome or caravan? This model boasts superb workmanship, materials, and operating convenience.
MORE DETAILS MORE DETAILS
Technical Information
Technical Information Colour Black Brand Dometic Scope of delivery S4S Top hung window with manual in box EAN-13 4015704232905 Publication Model Name Dometic S4 Product Description Top-hung hinged window, 600 x 500 mm Dimensions product height, [mm] 531 Dimensions product width, [mm] 644 Net weight, [kg] 6.10 Net weight, [lbs] 13.45 Dimensions parcel depth, [mm] 700 Dimensions parcel height, [mm] 185 Dimensions parcel width, [mm] 610 Parcel weight, [kg] 7.16 Parcel weight, [lbs] 15.79 Model identifier 11 1107 110703 110703005 Hinge type Top-hung Positions variable Variable SKUCertificates ECE R43 Dimensions ordered height, [mm] 500 Dimensions ordered width, [mm] 600 Standard mount. material thickness 1 min, [mm] 26 Standard mount. material thickness 1 max, [mm] 26 Possible material thickness 1 min, [mm] 27 Possible material thickness 1 max, [mm] 41 Cut out height, [mm] 498.000000 Cut out width, [mm] 599.000000 Dimensions product width, ["] - Display 25 5/16 Dimensions Ordered Height 500 Dimensions Ordered Width 600 Item Description S4 Top hung window, SL Dimensions Product Width Metric Display 644 Marketing Product Description Top-hung hinged window, 600 x 500 mm Dimensions Product Width Imperial Display 25 5/16 Legacy Item Number AAW40600X0500S Marketing Publication Model Name Dometic S4 Net Weight Imperial Display 13.45 Documentation & Downloads
