SKU: 9104115579
Looking for a top-quality, attractive window to enhance the side of your motorhome or caravan? This model boasts superb workmanship, materials, and operating convenience.
MORE DETAILS MORE DETAILS
Technical Information
Technical Information Colour Black Brand Dometic Scope of delivery S4S Top hung window with manual in box EAN-13 4015704233179 Publication Model Name Dometic S4 Product Description Top-hung hinged window, 1100 x 550 Dimensions product height, [mm] 581 Dimensions product width, [mm] 1148 Net weight, [kg] 10.10 Net weight, [lbs] 22.27 Dimensions parcel depth, [mm] 660 Dimensions parcel height, [mm] 185 Dimensions parcel width, [mm] 1220 Parcel weight, [kg] 12.40 Parcel weight, [lbs] 27.34 Model identifier 11 1107 110703 110703005 Hinge type Top-hung Positions variable Variable SKUCertificates ECE R43 Dimensions ordered height, [mm] 550 Dimensions ordered width, [mm] 1100 Standard mount. material thickness 1 min, [mm] 26 Standard mount. material thickness 1 max, [mm] 26 Possible material thickness 1 min, [mm] 27 Possible material thickness 1 max, [mm] 41 Cut out height, [mm] 549.000000 Cut out width, [mm] 1102.000000 Dimensions product width, ["] - Display 45 3/16 Dimensions Ordered Height 550 Dimensions Ordered Width 1100 Item Description S4 Top hung window, SL Dimensions Product Width Metric Display 1148 Marketing Product Description Top-hung hinged window, 1100 x 550 Dimensions Product Width Imperial Display 45 3/16 Legacy Item Number AAW41100X0550S Marketing Publication Model Name Dometic S4 Net Weight Imperial Display 22.27 Documentation & Downloads
