Dometic S4

Specificaties

Algemeen

Scope of delivery

S4S Window with manual in box

SKUCertificates

eMark

Product Description

Klapraam, 1600x600

Afmetingen

Dimensions product height, [mm]

631

Dimensions product width, [mm]

1650

Dimensions product width, ["] - Display

64 15/16

Dimensions ordered height, [mm]

600

Dimensions ordered width, [mm]

1600

Net weight, [kg]

16.20

Net weight, [lbs]

35.72

Standard mount. material thickness 1 min, [mm]

26

Standard mount. material thickness 1 max, [mm]

26

Possible material thickness 1 min, [mm]

27

Possible material thickness 1 max, [mm]

41

Cut out height, [mm]

599.000000

Cut out width, [mm]

1602.000000

Eigenschappen

Hinge type

Bovenscharnierend

Positions variable

Variable

Logistiek

Dimensions parcel depth, [mm]

720

Dimensions parcel height, [mm]

180

Dimensions parcel width, [mm]

1720

Parcel weight, [kg]

18.60

Parcel weight, [lbs]

41.01
