Dometic Brisk II - 15K BTU Single-Zone Air Conditioner w/Heat Pump - Black

Technical Information

Color

Black

Brand

Dometic

Scope of delivery

1 Air conditioner, 1 Warranty card, 1 Registration card

EAN-13

0713814204822

Publication Model Name

Dometic Brisk II - 15K BTU Single-Zone Air Conditioner w/Heat Pump - Black

Product Description

15,000 BTU - Rooftop Standard Profile Air Conditioner with Heat Pump - No Pre-installed controls - Non-Ducted application: air distribution box, CT controls and CT thermostat required - Ducted application: return air grille, CT controls and CT thermostat

Dimensions product depth, [mm]

701.68

Dimensions product height, [mm]

352.43

Dimensions product width, [mm]

752.48

Net weight, [kg]

34.93

Net weight, [lbs]

77

Dimensions parcel depth, [mm]

736.6

Dimensions parcel height, [mm]

381

Dimensions parcel width, [mm]

774.7

Parcel weight, [kg]

38.56

Parcel weight, [lbs]

85

GWP

2088

CO2 equivalent, [t]

1,302

Heating Capacity, [Btu/h] - Display

9629

Power consumption - Heat pump (ISO 5151)

1402

Model identifier

02 0206 020607 020607003

Thermostat control

Manual Thermostat

SKUCertificates

CSA

Hermetically Sealed

Yes

Refrigerant, type

R410A

Input voltage (AC), [V]

115

Input frequency, [Hz]

60

Required AC circuit protection min, [A]

20.000000

Required AC circuit protection max, [A]

20.000000

AirFlow, [m³h]

510.000000

Operating temperature min, [°C]

16.000000

Operating temperature max, [°C]

46.000000

Cut out height, [mm]

360.000000

Cut out width, [mm]

360.000000

Dimensions product width, ["] - Display

29 5/8

Item Description

Roof Top Unit
