Description
- High-performance design delivers 15 % air flow increase over previous models
- EPP foam housing reduces weight and increases cooling performance
- Easy installation and maintenance
- Requires inside ceiling assembly and control kit or ADB
- Custom-composite laminated shroud is UV-protected for lasting beauty
Specifications
SKU: 9105304463
| Model | 13.5K Btu |
|---|---|
| Scope of delivery | 1 Air conditioner, 1 Warranty card, 1 Registration card |
| SKUCertificates | CSA |
| Product Description | 13,500 BTU - Rooftop Standard Profile Air Conditioner - No Pre-installed controls - Non-Ducted application: air distribution box required - Ducted application: return air grille and control kit required - white |
| Dimensions product depth, [mm] | 701.68 |
|---|---|
| Dimensions product height, [mm] | 352.42 |
| Dimensions product width, [mm] | 752.47 |
| Dimensions product width, [in] | 29 5/8 |
| Net weight, [kg] | 34.93 |
| Net weight, [lbs] | 77 |
| Input voltage (AC), [V] | 115 |
|---|---|
| Input frequency, [Hz] | 60 |
| Required AC circuit protection min, [A] | 20 |
| Required AC circuit protection max, [A] | 20 |
| Hermetically Sealed | Yes |
|---|---|
| Refrigerant, type | R410A |
| GWP | 2088 |
| CO2 equivalent, [t] | 0,947 |
| AirFlow, [m<sup>3</sup>h] | 520 |
| Cooling Capacity ISO5151 Display | 3956.46 |
| Cooling Capacity Display | 13500 |
| Operating temperature min, [°C] | 16 |
| Operating temperature max, [°C] | 48 |
| Thermostat control | Manual Thermostat |
|---|
| Dimensions parcel depth, [mm] | 736.6 |
|---|---|
| Dimensions parcel height, [mm] | 381 |
| Dimensions parcel width, [mm] | 774.7 |
| Parcel weight, [kg] | 38.56 |
| Parcel weight, [lbs] | 85 |
Highlights
High-performance design
Larger air openings for improved air flow and cooling
Lighter weight
EPP foam housing reduces weight and also improves cooling
Lasting Design
Custom wrap-around shroud and carbon steel base add strength, protection and durability
Quiet Operation
Dampening brackets reduce noise and vibration
Superior climate control
What makes Brisk air conditioners best-in-class of any standard RV rooftop air conditioner for their weight, air flow and capacity? There are various factors that combine to achieve market leading results. These include the large air openings which promote superior air flow and cooling capacity, while the EPP foam housing both reduces weight and also contributes to improved cooling. The Brisk is incredibly robust, components such as its carbon steel base have proven their durability by coming through vibration tests lasting for 30 hours and more! The optional heater function is ideal for use on cool evenings, with a multispeed blower for users to adjust according to their cooling or heating needs. Finally, great care has been taken to reduce operating noise: with the motor, compressor and evaporator bracketed together for vibration-free, quiet operation. Long copper lines and dual rubber bushings are also responsible for minimizing noise and vibration. Allowing you to enjoy comfortable temperatures in peace and quiet!
