Description
- This low profile flat deck Slimsport rack has a load carrying area of 1272mm (50.07" ) x 1135mm (44.68").
- The sleek side rails have integrated mounting feet. Mounting feet also have additional brace brackets for added strength.
- The high-strength aluminum slats have top and bottom T-slots suitable for all Front Runner top mount accessories.
- Easily add on the Rack Accessory Mounting Bracket Slimsport Side Mount Accessory Bracket / Small (sold separately) for all Front Runner side mount accessories.
- The included standard full fairing with rubber edge trim, makes the rack ultra-quiet.
- Need a lightbar? The optional lightbar fairing Toyota Hilux (2015-Current) Slimsport Rack 40" Light Bar Wind Fairing (sold separately) has a 40" cutout to allow use of 40" LED Light Bar FX1000-CB SM / 12V/24V / Single Mount (sold separately).
- Fitment guide and all mounting hardware included.
- Note: Drilling required.
Specifications
SKU: KSTH003T
KSTH003T - Toyota Hilux DC (2015-2021) Slimsport Roof Rack Kit - by Front Runner
Consisting of:
1 x Toyota Hilux DC (2015-2021) Slimsport Roof Rack Kit
1 x RRAC232 - TOYOTA HILUX SLIMSPORT RACK WIND FAIRING
Installation Hardware
Fitting Instructions
Material Used:
Black epoxy powder - coated T6 aluminium
High strength steel
Assembled Rack Kit Dimensions:
1398mm (55“) L x 1141mm (44.9“) W x 106mm (4.2“) H
Approximate Installed Weight: 25.55kg (56.33lbs)
The t-slots on the tops and bottoms of the slats accommodate standard 8mm bolts.
To determine the approximate height from your vehicle’s roof to the top of your Slimsport Rack add 60mm-70mm (2.4"-2.8") to the highest point of your roof.
Shipping Dimensions:
Width: 325mm (13")
Length: 1700mm (67")
Height: 160mm (6")
Shipping Weight:
Weight: 25.55kg (56lbs)
