Dometic Penguin II - Hi Cap Air Conditioner w/Heat Pump - White

Technical Information

Color

Black

Brand

Dometic

Model

Hi Cap Heatpump with Control Box

Scope of delivery

1 Air conditioner, 1 Warranty card

EAN-13

0713814216580

Publication Model Name

Dometic Penguin II - Hi Cap Air Conditioner w/Heat Pump - White

Product Description

High Capacity (Approximately 15,000 BTU) - Rooftop Low Profile Air Conditioner with Heat Pump - No pre-installed controls - Non-Ducted application Only: air distribution box required - white

Dimensions product depth, [mm]

736.60

Dimensions product height, [mm]

285.75

Dimensions product width, [mm]

1028.70

Net weight, [kg]

43.90

Net weight, [lbs]

96.80

Dimensions parcel depth, [mm]

755

Dimensions parcel height, [mm]

310

Dimensions parcel width, [mm]

1055

Parcel weight, [kg]

49.50

Parcel weight, [lbs]

109.15

GWP

2088

CO2 equivalent, [t]

1.357

Thermostat control

Manual Thermostat

SKUCertificates

CSA

Standard mount. material thickness 1 min, [mm]

25

Standard mount. material thickness 1 max, [mm]

150

Hermetically Sealed

Yes

Refrigerant, type

R410A

Input voltage (AC), [V]

115

Input frequency, [Hz]

60

Operating temperature min, [°C]

-7.000000

Operating temperature max, [°C]

52.000000

Cut out depth, [mm]

360.000000

Cut out width, [mm]

360.000000

Dimensions product width, ["] - Display

40 1/2

Item Description

Dometic, PENGUIN HP MECH PW 410A

Pack Size

Yes
