Dometic CFX3 45

Technical Information

Colour

Black

Brand

Dometic

Scope of delivery

1 cooler, 1 manual, 1 Connection cable for 12/24V connection, 1 Connection cable for 100-240V connection, removable wire baskets

EAN-13

7315091514705

Publication Model Name

Dometic CFX3 45

SEO Publication Name

CFX3 45 Electric Cooler

Product Description

Mobile compressor cooler and freezer, 46 l

Dimensions product depth, [mm]

694

Dimensions product height, [mm]

476

Dimensions product width, [mm]

398

Net weight, [kg]

19.40

Net weight, [lbs]

42.78

Dimensions parcel depth, [mm]

733

Dimensions parcel height, [mm]

512

Dimensions parcel width, [mm]

438

Parcel weight, [kg]

22.60

Parcel weight, [lbs]

49.83

GWP

1430

CO2 equivalent, [t]

0.06

Rated input current (AC), [A]

0.96A at 100V, 0.40A at 240V

Rated input current (DC), [A]

8.2

Rated input power (AC), [W]

52

USB Port

5V, 2A

Connectivity Type

Bluetooth, Interact, WiFi

Basket

Yes

Threaded inserts in base for mounting

M6

Drain plug

Yes

Anti-condensation coil

Yes

Single or Dual Zone

Single

Thermostat control

Electronic Thermostat

Hinge type

Top

Interior light

Yes, LED

SKUCertificates

G-mark

Total volume (IEC 62552-3), [l]

46.000000

Amount of cans (12oz/375ml)

67

Hermetically Sealed

Yes

Refrigerant, type

R134a

Input voltage (AC), [V]

100-240

Input voltage (DC), [V]

12/24

Input frequency, [Hz]

50/60

Priority circuit (Integrated)

Yes

Noise (EN60704-1 & 60704-2-14), [dB(A)]

47.000000

Climate class (EN 62552)

N/T

Operating temperature min, [°C]

16.000000

Operating temperature max, [°C]

43.000000

Insulation Type

PU (Polyurethane)

Dimensions product width, ["] - Display

15.67

Item Description

CFX345, AC/DC, AR Version, 5VA

Pack Size

Yes
