- Two Cooling Zones
- VIP – Exceptionally efficient insulation
- Powerful Compressor
The CFX5 75DZ is a fan favorite. One of our largest compressor coolers – great for a van’s portable cooler or long camping trips. Dual storage compartments with independent temperature control and two cooling zones. Super-efficient Vacuum Insulated Panels deliver outstanding insulation, and maximum energy efficiency. You can control it with our Mobile Cooling smartphone app, a steel frame protects, it’s solar compatible, and – cheers – a bottle opener’s built in.
Description
- The 75L (45/30) capacity holds up to 128 x 330ml cans & 22 x 1,5L bottles – a large size for weekend adventures, week-long camping trips, and extended nomadic travel
- Temperature range can be set between +20°C to -22°C
- Control your cooler, track energy consumption and monitor temperature with the cooler’s Mobile Cooling smartphone app; be alerted when lid is left over, monitor history, and connect multiple devices at once
- Optimized ratio of exterior to interior proportions provides maximum compressor efficiency, while the extended evaporator on inner walls ensures an even distribution of cold air
- Powered by AC (110-240V), DC (12/24V) – or go off-grid with Dometic portable batteries and solar panels
- 3-stage dynamic battery protection system actively monitors inbound power and prevents draining a vehicle battery or allows deep draw on dual batteries
- Two cooling zones allow you to individual cooling for your food and drinks at once
- 3 years warranty
Specifications
SKU: 97000050763
| Model | CFX575DZ |
|---|---|
| Scope of delivery | 1 cooler; 1 manual; 1 DC connection cable, 2 AC connection cable, removeable wire basket |
| SKUCertificates | GMark;ECER10;UKCA;CB;EMC;GS |
| Product Description | Performance Dual-Zone Compressor Cooler, 75L |
| Dimensions product depth, [mm] | 892.05 |
|---|---|
| Dimensions product height, [mm] | 471.93 |
| Dimensions product width, [mm] | 495.05 |
| Dimensions product width, [in] | 19.49 |
| Net weight, [kg] | 27.04 |
| Net weight, [lbs] | 59.62 |
| Total volume (IEC 62552-3), [l] | 75 |
| Amount of cans (12oz/375ml) | 121 |
| Input voltage (AC), [V] | 100-240 |
|---|---|
| Input voltage (DC), [V] | 12/24 |
| Rated input current (AC), [A] | 1.10A at 100V; 0.47A at 240V |
| Rated input current (DC), [A] | 4.6A at 24V, 9.8A at 12V |
| Rated input power (AC), [W] | 59 |
| Input frequency, [Hz] | 50/60 |
| Battery type | Not Applicable (NA) |
| Priority circuit (Integrated) | Yes |
| Hermetically Sealed | Yes |
|---|---|
| Refrigerant, type | R600a |
| Energy Consumption 12VDC (4 °C large zone, -15 °C small zone, 32 °C ambient), [Ah/h] | 2.45 |
| Energy efficiency class (Regulation (EU) 2019/2016) | C |
| Climate class (EN 62552) | N/T |
| Operating temperature min, [°C] | 16 |
| Operating temperature max, [°C] | 43 |
| Insulation Type | PU (Polyurethane) |
| USB Port | Yes |
|---|---|
| Connectivity Type | Bluetooth |
| Basket | Yes |
| Threaded inserts in base for mounting | M6 |
| Drain plug | Yes |
| Anti-condensation coil | Yes |
| Single or Dual Zone | Dual |
| Thermostat control | Electronic Thermostat |
| Interior light | Yes, LED |
| Dimensions parcel depth, [mm] | 934.97 |
|---|---|
| Dimensions parcel height, [mm] | 519.94 |
| Dimensions parcel width, [mm] | 534.92 |
| Parcel weight, [kg] | 30.44 |
| Parcel weight, [lbs] | 67.10 |
Videos
Highlights
Two Cooling Zones
Dual zones let you set separate temps in separate compartments
VIP – Exceptionally efficient insulation
VIPs – Vacuum Insulated Panels – superb energy efficiency, VIPs minimize thermal transfer through superior sealing and air removal techniques
Powerful Compressor
Variable Motor Speed Optimization Technology automatically adjusts speed for optimal performance
High Resolution Display
Easy-to-read, weatherproof, high-resolution TFT color operating display, with 18W QC 3.0 USB port, and soft-touch buttons
Smartphone Connectivity
Temperature and cooler control and performance monitoring via Dometic Mobile Cooling app
Durable Exoframe design
Reinforced corners and edges, and folding handles that help you take it anywhere
3-Year Warranty
Enjoy extra peace of mind with a three‑year manufacturer’s warranty.
ISPO Award Winner 2025
“For those who chase horizons rather than deadlines, the Dometic CFX5 Series isn’t just a cooler, it’s the silent backbone of adventure. Efficient, durable, and engineered for life off the beaten path, it represents a shift toward smarter, more sustainable exploration.“—ISPO Jury
2 questions
VIPs – Vacuum Insulated Panels – the latest electric cooler insulation technology,
that keeps your cooler cold, light, and efficient.
Just like the insulation in your water bottle – by eliminating gas molecules, VIPs drastically reduce heat transfer. The result? Your CFX5 stays cold with less energy, while remaining compact and lightweight. More efficiency, more cooling, less bulk.
Benefits of VIP:
Effective Thermal Insulation: VIP creates a near-perfect vacuum, drastically reducing heat transfer and preventing convective heat loss.
Reliable Cooling: VIP ensures stable temperatures, even in harsh conditions, keeping your items consistently chilled.
Energy Efficient: The advanced insulation reduces power consumption, making it ideal for extended off-grid use without sacrificing cooling performance.
Lightweight Design: VIP allows for thinner insulation, keeping the cooler both lightweight and easy to carry.
Yes, cleaning your CFX electric cooler is simple. Just wipe down the interior and exterior surfaces with a mild cleaning solution and a towel. Regular cleaning helps maintain the hygiene and longevity of your cooler.
