Description
- Effective air exchange even when all windows and doors are closed
- Patented heat recovery system reduces the energy consumption for heating and A/C system
- Integrated air purifier system reduces dust particles, mold and odors
- Smart sensor technology monitors the air quality and triggers the required venting rate
- Ventilation during storage periods prevents mold build-up and unpleasant smells
- LED light strip casts a beautiful ambient light
- Manage all functions from your smart phone via the new Dometic Climate App
- Low profile rooftop unit: space-saving, lightweight, aerodynamic and aesthetically pleasing
- Fits standard 400 x 400 mm roof cut-outs or 360 x 360 mm window frames
Specifications
SKU: 9620005072
| Model | ACC3100D |
|---|---|
| Product Description | RV ventilation system with energy recovery |
| Dimensions product depth, [mm] | 553 |
|---|---|
| Dimensions product height, [mm] | 220 |
| Dimensions product width, [mm] | 537 |
| Dimensions product width, [in] | 21.14 |
| Net weight, [kg] | 7 |
| Net weight, [lbs] | 15.44 |
| Connectivity Type | Bluetooth |
|---|
| Dimensions parcel depth, [mm] | 600 |
|---|---|
| Dimensions parcel height, [mm] | 280 |
| Dimensions parcel width, [mm] | 565 |
| Parcel weight, [kg] | 8.35 |
| Parcel weight, [lbs] | 18.41 |
Highlights
Draught-free ventilation
Effective air exchange even when all windows and doors are closed
Clever reuse of energy
Patented heat recovery system reduces the energy consumption for heating and A/C system
Clean and healthy air
Integrated air purifier system reduces dust particles, mold and odors
Fully automatic operation
Smart sensor technology monitors the air quality and triggers the required venting rate
Less work to do off-season
Ventilation during storage periods prevents mold build-up and unpleasant smells
Sleek design
Low profile rooftop unit: space-saving, lightweight, aerodynamic and aesthetically pleasing
Integrated lighting
LED light strip casts a beautiful ambient light
Easy-to-install standard size
Fits standard 400 x 400 mm roof cut-outs or 360 x 360 mm window frames
Convenient remote control
Manage all functions from your smart phone via the new Dometic Climate App
CleanAir technology
The air purifier integrated in the Dometic FanTastic Breathe 3100 rooftop ventilation system uses advanced bipolar ionization technology to ensure you can always breathe fresh and healthy air. Here’s how it works. When voltage is applied to the two needle-point brushes of the air purifier, they interact with the oxygen and moisture in the air to produce negative and positive ions. These ions have three positive effects. First, they help reduce bacteria, viruses and mold by attacking their core structure. Second, the charged ions attract the dust particles in the air. This creates larger lumps of particles, which can be easily caught in the dust filter. Third, the ions break down the molecular structure of volatile organic compounds. This eliminates unpleasant smells caused by chemicals or waste.
