Dometic Freshjet 4 Series Essential

Technical Information

Colour

Black

Brand

Dometic

Scope of delivery

Roof top unit, manuals

EAN-13

6975399590132

Publication Model Name

Dometic Freshjet 4 Series Essential

Dimensions product depth, [mm]

752

Dimensions product height, [mm]

225

Dimensions product width, [mm]

702

Net weight, [kg]

30.40

Net weight, [lbs]

67.03

Dimensions parcel depth, [mm]

816

Dimensions parcel height, [mm]

278

Dimensions parcel width, [mm]

756

Parcel weight, [kg]

35.10

Parcel weight, [lbs]

77.40

GWP

675

CO2 equivalent, [t]

0.243

SKUCertificates

CB;CE;ECER10;RCM

Standard mount. material thickness 1 min, [mm]

25

Standard mount. material thickness 1 max, [mm]

60

Hermetically Sealed

Yes

Refrigerant, type

R32

Input voltage (AC), [V]

220-240

Input frequency, [Hz]

50

AirFlow, [m³h]

428.000000

Current consumption max cooling, [A]

6.000000

Operating temperature min, [°C]

-2.000000

Operating temperature max, [°C]

52.000000

Cut out depth, [mm]

400.000000

Cut out width, [mm]

400.000000

Dimensions product width, ["] - Display

27.64

Item Description

Dometic Shape 2200W FS HS WHT R32, AM, RTU, APAC

Pack Size

Yes
