Description
- Convenient 12 or 24 V DC and 240 V AC cooler
- Refrigerates down to 27 °C below ambient temperature, heats up to +65 °C
- Active battery protection prevents deep discharge of the vehicle battery
- Very efficient TC special electronics with intelligent power-save circuit
- Reverse polarity protection for hassle-free electrical connections
- Priority circuit for mains operation
- Wear-resistant fan for dynamic interior ventilation
- 2-stage battery protection
Specifications
SKU: 9600013319
| Model | TCX14 |
|---|---|
| Scope of delivery | 1 Cooling device, 1 Connection cable for cigarette lighter, 1 Connection cable for 220-240V, 1 User manual |
| SKUCertificates | GMark;CE;ECER10;GS |
| Product Description | Portable thermoelectric cooler, 15 l |
| Dimensions product depth, [mm] | 450 |
|---|---|
| Dimensions product height, [mm] | 328 |
| Dimensions product width, [mm] | 303 |
| Dimensions product width, [in] | 11.93 |
| Net weight, [kg] | 6.70 |
| Net weight, [lbs] | 14.77 |
| Total volume (IEC 62552-3), [l] | 15 |
| Input voltage (AC), [V] | 220-240 |
|---|---|
| Input voltage (DC), [V] | 12/24 |
| Rated input current (AC), [A] | 0.6A@AC230V |
| Rated input current (DC), [A] | 3.8A@DC12V,2.1A@DC24V |
| Rated input power (AC), [W] | 64 |
| Input frequency, [Hz] | 50/60 |
| Hermetically Sealed | Yes |
|---|---|
| Energy efficiency class (Regulation (EU) 2019/2016) | E |
| Climate class (EN 62552) | T |
| Insulation Type | PU (Polyurethane) |
| Single or Dual Zone | Single |
|---|---|
| Thermostat control | Electronic Thermostat |
| Dimensions parcel depth, [mm] | 470 |
|---|---|
| Dimensions parcel height, [mm] | 320 |
| Dimensions parcel width, [mm] | 350 |
| Parcel weight, [kg] | 7.80 |
| Parcel weight, [lbs] | 17.20 |
Highlights
Optional fixing kit
For TropiCool TCX 14, TCX 21, TCX 35: for fastening of TropiCool coolers in vehicles
Energy Saving
Intelligent power-save circuit
Versatile
Operates even in tilted positions
High-performance luxury
Soft-touch control panel: perfect down to the last detail
Cool and heat
Can operate as refrigerator or heater
Keep Custom Settings
Memory feature maintains presets if the system is turned off
The next generation TropiCool
A fresh design, soft-touch controls and digital display – these are the hallmarks of the Dometic TropiCool TCX series. What’s more, the popular high-tech coolers deliver a reliably high performance with features including: intelligent power save circuit, an individually adjustable temperature, cooling performance up to 27 °C below the ambient temperature and, if desired, a heating function achieves temperatures of up to +65 °C. The new TCX coolers prevent deep discharging when connected to a battery and feature reverse polarity protection for DC and AC connections.
