Dometic CFX3 75DZ

Specifications

General

Scope of delivery

1 cooler, 1 manual, 1 Connection cable for 12/24V connection, 1 Connection cable for 100-240V connection, removable wire baskets

SKUCertificates

ECER10;CB;CE

Product Description

Mobile dual-zone compressor cooler and freezer, 74 l

Dimensions

Dimensions product depth, [mm]

495

Dimensions product height, [mm]

472

Dimensions product width, [mm]

892

Dimensions product width, ["] - Display

35.12

Net weight, [kg]

27.8

Net weight, [lbs]

61.29

Total volume (IEC 62552-3), [l]

74.000000

Amount of cans (12oz/375ml)

113

Electrical

Input voltage (AC), [V]

100-240

Input voltage (DC), [V]

12/24

Rated input current (AC), [A]

1.12A at 100V, 0.47A at 240V

Rated input current (DC), [A]

9.6

Rated input power (AC), [W]

59

Input frequency, [Hz]

50/60

Priority circuit (Integrated)

Yes

Performance

Hermetically Sealed

Yes

Refrigerant, type

R134a

GWP

1430

CO2 equivalent, [t]

0.084

Noise (EN60704-1 & 60704-2-14), [dB(A)]

50.000000

Climate class (EN 62552)

N/T

Insulation Type

PU (Polyurethane)

Properties

USB Port

5V, 2A

Connectivity Type

Bluetooth

Basket

Yes

Threaded inserts in base for mounting

M6

Drain plug

Yes

Anti-condensation coil

Yes

Single or Dual Zone

Dual

Thermostat control

Electronic Thermostat

Hinge type

Right hinged

Interior light

Yes, LED

Logistics

Dimensions parcel depth, [mm]

525

Dimensions parcel height, [mm]

520

Dimensions parcel width, [mm]

930

Parcel weight, [kg]

32.39

Parcel weight, [lbs]

71.42
