Description
Mazimize chiller efficiency and reduce electrical load fluctuations with Dometic's innovative Variable Capacity Chiller (VARCX). Now with titanium condensers!
Specifications
SKU: 9600026333
| Model | Chiller Cond VARCX |
|---|---|
| Product Description | Variable Capacity Titanium Chiller, 120 000 BTU/h |
| Dimensions product depth, [mm] | 647.7 |
|---|---|
| Dimensions product height, [mm] | 609.6 |
| Dimensions product width, [mm] | 336.55 |
| Net weight, [kg] | 86 |
| Input voltage (AC), [V] | 230 |
|---|---|
| Input frequency, [Hz] | 50/60 |
| Required AC circuit protection min, [A] | 50 |
| Required AC circuit protection max, [A] | 50 |
| Hermetically Sealed | Yes |
|---|---|
| Refrigerant, type | R410A |
| GWP | 2088 |
| CO2 equivalent, [t] | 5.62 |
| Cooling Capacity ISO5151 Display | 21101.12 |
| Cooling Capacity Display | 120000 |
| Current consumption min cooling, [A] | 20.1 |
| Current consumption max cooling, [A] | 20.1 |
| Dimensions parcel depth, [mm] | 1092.2 |
|---|---|
| Dimensions parcel height, [mm] | 1219.2 |
| Dimensions parcel width, [mm] | 939.8 |
| Parcel weight, [kg] | 213.38 |
Dometic Chilled Water System - Installation and Operating Manual - AMER(en)
Installation And Operating Manual
Dometic VARCX (PLC Chiller Controls) - Installation and Operating Manual - Marine INT24
Installation And Operating Manual
