The CFX5 35 is a super-versatile size – holds up to 56 x 330 ml cans & 6 x 1,5 l bottles and is easy to carry – make it your compressor coolbox for camping trips and family outings. The highly efficient Vacuum Insulated Panels deliver outstanding insulation maximum energy efficiency, the lid’s gasket seals tight, and the compressor offers powerful and energy efficient cooling. Control it with our smartphone app and stay adventure ready.
SKU: 97000050760
| Model | CFX535 |
|---|---|
| Scope of delivery | 1 cooler; 1 manual; 1 DC connection cable, 2 AC connection cable, removeable wire basket |
| SKUCertificates | GMark;ECER10;UKCA;CB;EMC;GS |
| Product Description | Performance Compressor Coolbox, 36 l |
| Dimensions product depth, [mm] | 693.93 |
|---|---|
| Dimensions product height, [mm] | 406.91 |
| Dimensions product width, [mm] | 398.02 |
| Net weight, [kg] | 16.57 |
| Total volume (IEC 62552-3), [l] | 36 |
| Amount of cans (12oz/375ml) | 121 |
| Input voltage (AC), [V] | 100-240 |
|---|---|
| Input voltage (DC), [V] | 12/24 |
| Rated input current (AC), [A] | 1.00A at 100V; 0.41A at 240V |
| Rated input current (DC), [A] | 3.8A at 24V, 8.9A at 12V |
| Rated input power (AC), [W] | 42 |
| Input frequency, [Hz] | 50/60 |
| Battery type | Not Applicable (NA) |
| Priority circuit (Integrated) | Yes |
| Hermetically Sealed | Yes |
|---|---|
| Refrigerant, type | R600a |
| Energy Consumption 12VDC (Ambient@32C, Internal@4C), [Ah/h] | 0.77 |
| Energy efficiency class (Regulation (EU) 2019/2016) | B |
| Climate class (EN 62552) | N/T |
| Operating temperature min, [°C] | 16 |
| Operating temperature max, [°C] | 43 |
| Insulation Type | PU (Polyurethane) |
| USB Port | Yes |
|---|---|
| Connectivity Type | Bluetooth |
| Basket | Yes |
| Threaded inserts in base for mounting | M6 |
| Drain plug | Yes |
| Anti-condensation coil | Yes |
| Single or Dual Zone | Single |
| Thermostat control | Electronic Thermostat |
| Interior light | Yes, LED |
| Dimensions parcel depth, [mm] | 730 |
|---|---|
| Dimensions parcel height, [mm] | 454.91 |
| Dimensions parcel width, [mm] | 435.10 |
| Parcel weight, [kg] | 19 |
VIPs – Vacuum Insulated Panels – superb energy efficiency, VIPs minimise thermal transfer through superior sealing and air removal techniques
Variable Motor Speed Optimisation Technology automatically adjusts speed for optimal performance
Easy-to-read, weatherproof, high-resolution TFT colour operating display, with 18W QC 3.0 USB port, and soft-touch buttons
Temperature and coolbox control and performance monitoring via Dometic Mobile Cooling app
Reinforced corners and edges, and folding handles that help you take it anywhere
2 questions
VIPs – Vacuum Insulated Panels – the latest electric cooler insulation technology,
that keeps your cooler cold, light, and efficient.
Just like the insulation in your water bottle – by eliminating gas molecules, VIPs drastically reduce heat transfer. The result? Your CFX5 stays cold with less energy, while remaining compact and lightweight. More efficiency, more cooling, less bulk.
Benefits of VIP:
Effective Thermal Insulation: VIP creates a near-perfect vacuum, drastically reducing heat transfer and preventing convective heat loss.
Reliable Cooling: VIP ensures stable temperatures, even in harsh conditions, keeping your items consistently chilled.
Energy Efficient: The advanced insulation reduces power consumption, making it ideal for extended off-grid use without sacrificing cooling performance.
Lightweight Design: VIP allows for thinner insulation, keeping the cooler both lightweight and easy to carry.
Yes, cleaning your CFX electric cooler is simple. Just wipe down the interior and exterior surfaces with a mild cleaning solution and a towel. Regular cleaning helps maintain the hygiene and longevity of your cooler.
