Modular Titanium Chiller available from 24,000 BTU/h to 180,000 BTU/h
SKU: 9108915839
Dometic MCGX modular chillers use titanium condensers to greatly increase durability and product lifespan. Titanium is unaffected by the punishing combination of saltwater, invasive marine life, and the harsh acids used for routine cleaning of the condenser coil. Titanium extends service life and is unaffected by the corrosion and erosion of the harsh marine environment.
Technical Information
Technical Information
Color
Black
Brand
Dometic
EAN-13
7315091242677
Publication Model Name
Dometic MCGXLP CW Module
Product Description
Modular Titanium Chiller available from 24,000 BTU/h to 180,000 BTU/h
Dimensions product depth, [mm]
431.80
Dimensions product height, [mm]
939.80
Dimensions product width, [mm]
889
Net weight, [kg]
79.38
Net weight, [lbs]
175
Dimensions parcel depth, [mm]
889
Dimensions parcel height, [mm]
939.8
Dimensions parcel width, [mm]
431.8
Parcel weight, [kg]
99.92
Parcel weight, [lbs]
220.3
GWP
2088
CO2 equivalent, [t]
1,835
Hermetically Sealed
Yes
Refrigerant, type
R410A
Input voltage (AC), [V]
230
Input frequency, [Hz]
60
Required AC circuit protection min, [A]
45.000000
Required AC circuit protection max, [A]
81.000000
Current consumption min cooling, [A]
14.200000
Current consumption max cooling, [A]
14.200000
Dimensions product width, ["] - Display
35
Cooling Capacity Display
72000
Item Description
MCGXLP72 2363
Dimensions Product Width Metric Display
889
Marketing Product Description
Modular Titanium Chiller available from 24,000 BTU/h to 180,000 BTU/h
