This DC charging converter transforms 12 V input voltage to 24 V and ensures that the leisure battery is optimally charged during the drive at all times – so you will never end up with an empty battery when you arrive at your destination. Highly recommendable for modern EURO 6 vehicles with smart alternators. And also for vehicles where the cable cross section is too small to supply the connected devices.
Technical Information
Technical Information
Color
Black
Brand
Dometic
EAN-13
4015704266382
Publication Model Name
Dometic PerfectPower DCC 1224-10
Product Description
Charging converter 12 V to 24 V, 10 A
Dimensions product depth, [mm]
220
Dimensions product height, [mm]
73
Dimensions product width, [mm]
153
Net weight, [kg]
1.55
Net weight, [lbs]
3.42
Dimensions parcel depth, [mm]
237
Dimensions parcel height, [mm]
90
Dimensions parcel width, [mm]
160
Parcel weight, [kg]
1.70
Parcel weight, [lbs]
3.75
Energy efficiency, [%]
≤89
Connectivity Type
None
Input voltage (DC), [V]
12
Battery type
AGM, Gel, Lead
Continuous power 25°C, [W]
250.000000
Operating temperature min, [°C]
-20.000000
Operating temperature max, [°C]
50.000000
Dimensions product width, ["] - Display
6.02
Item Description
Charge Converter for vehicle batteries, 12V to 24V, 10A max., 250W
