Image 1 of 5

Dometic GVTX10

Climatiseur monobloc de capacité variable, 6 000 à 10 000 BTU/h

  • Variable capacity compressor
  • Robust and stylish
  • Titanium condenser coil

Notre climatiseur monobloc pour bateau utilise le fluide réfrigérant R-454b avec un impact environnemental réduit. La technologie de vitesse variable garantit une efficacité plus élevée grâce au réglage de la capacité selon vos besoins. Doté de spirales robustes en titane résistantes à la corrosion, le GTX réchauffe et rafraîchit agilement et silencieusement la pièce. Le plateau de récupération en composite anti-corrosion garantit un design propre.

Description

  1. Engineered to maximize the performance of R-454B refrigerant
  2. Variable capacity for on-demand cooling and constant temperature
  3. High-static DC blower and optional sleep mode ensure quiet performance
  4. Multi-voltage for worldwide operation
  5. Robust design with non-corrosive composite drain pan and titanium condenser
  6. Cooling and heating capabilities
  7. Built-in NMEA2000 network for complete connectivity

Spécifications

SKU: 9610006985

Dometic GVTX10 — Général, spécifications
ModelGVTX
Product DescriptionClimatiseur monobloc de capacité variable, 6 000 à 10 000 BTU/h

Dometic GVTX10 — Électrique, spécifications
Input voltage (AC), [V]115 - 230
Input frequency, [Hz]50/60
Required AC circuit protection min, [A]12
Required AC circuit protection max, [A]15

Dometic GVTX10 — Performance, spécifications
Hermetically SealedOui
Refrigerant, typeR454B
GWP465
CO2 equivalent, [t]0.12
Cooling Capacity Display10000
Current consumption min cooling, [A]6.6
Current consumption max cooling, [A]6.6

Dometic GVTX10 — Logistique, spécifications
Dimensions parcel depth, [mm]609.60
Dimensions parcel height, [mm]508
Dimensions parcel width, [mm]457.20
Parcel weight, [kg]21.79

Dometic GVTX Self Contained - Declaration of Conformity EU EMEA24
Declaration Of Conformity
Dometic DCU, DLU, DTG, ECD, GT, GTX, GTX-LP, GVTX, TX - Installation Manual INT24
Installation Manual
Dometic DCU, DLU, DTG, ECD, GT, GTX, GTX-LP, GVTX, TX - Safety Information INT5
Safety Information
Dometic DCU, DLU, DTG, ECD, GT, GTX, GTX-LP, GVTX, TX - Safety Information INT5
Safety Information
Dometic Climate Parts Guide.pdfanglais américain
GVTX Leaflet.pdfanglais américain
Product Leaflet

Vidéos

Ajouter les essentiels

Highlights

Variable capacity compressor

Adjusts to demand for extreme power efficiency

Robust and stylish

With composite positive flow condensate pan

Titanium condenser coil

Robust design ensure reliable performance

High velocity rotatable blower

Great air distribution and installation flexibility

Sound cover as standard

Ultra quiet night-time operation

Ensure comfort without interruptions

Ensure comfort without interruptions

The Dometic GVTX series does not draw starting amperage like a standard air-conditioning system. Instead, its intelligent system “slow starts” the compressor. This eliminates the chance of a power surge which could cause a trip to the boat’s power breaker. So you can enjoy easy climate control, without disturbing the performance of your boat's other electronics.
